Each kit contains the following:
| |
15m Kit |
30m Kit |
60m Kit |
90m Kit |
| Gull Wire 0.96mm 1 X 7 304 Stainless Nylon Coated |
50m |
100m |
150m |
200m |
| Gull Post 150mm Single Headed For Surface Mounting |
12 |
22 |
42 |
62 |
| Grey Surface Mount Base |
16 |
26 |
46 |
66 |
| Gull Wire Micro Spring |
10 |
20 |
40 |
60 |
| Gull Wire 1mm Copper Crimp |
100 |
100 |
100 |
200 |
| Silicone Adhesive 300ml |
1 |
1 |
1 |
1 |
| Surface Activator |
1 |
1 |
1 |
1 |
| Bird Wire Crimp Tool |
1 |
1 |
1 |
1 |
This kit is intended for use on non-masonry substrates that can not take anchor rivets, including metal, plastic and glass. If you require post & wire to be used on masonry substrates then you should consider using our post and wire masonry kit or our range of specialist brackets for gutters, steel beams, pipes or rails.
This surface mount kit for seagull post and wire provides suffidcient materials for a run of 150mm single-head posts. Parallel rows should be set no more than 100mm apart (max 100mm behind first row).
Once the posts are seated in their surface mount bases the heads of the posts will be at 150mm.
Maximum distance between seagull wire posts = 3000mm (3m)
Seagull wire should be spring-tensioned every 3000mm (3m) along its run, i.e. the wire should stop at a spring on each post and start with a newly crimped section of the other side of the post.
In doing so you are spreading the load evenly across the post system and thus avoiding spring overload
Do not thread the pigeon wire through the eyelets of the post and onwards to the next post, as this will cause the system to sag and go out of shape.
The system should be counter-tensioned at the end of each run using the screw-pin and plugs provided. To avoid the system from sagging do not use springs in the counter-tension wires.
