• For use with our NT124 Pneumatic Hog Ring Staple Gun
• Available in stainless or galvanised steel cheaper and faster than SR8 staples
• Used for securing bird netting to perimeter wire rope on large projects
• Can also be used for forming weldmesh enclosures including chimney cages
• Equivalent to King Hughes 516G100 staples

• Open: ½” Crown (0.050” / 1.27mm)
• Closed: 1/8” Diameter (0.125” / 3.175mm)
• Wire: 16 gauge (0.0625” / 1.60mm)
• Tips: Sharpened

Joining bird control netting to perimeter / cross wires

Installing access zips into bird control netting

Forming weldmesh enclosures, including chimney cages

Simply slide the magazine of staples on to the feeder arm of the pneumatic hog ring gun, the automated mechanism will then feed staples into the gun as required

We recommend the use of our galvanised steel staples for indoor use or sheltered outdoor use such as loading docks and warehouse cannopies. We recommend the use of stainless steel staples for outdoor use and especially in coastal or marine applications.

Hog Ring Spacing

• 75mm mesh nets, 1 ring per square
• 50mm mesh nets, 1 ring every other square
• 40mm mesh nets, 1 ring every other square
• 28mm mesh nets, 1 ring every other square
• 19mm mesh nets, 1 ring every three squares
